Fine Adjust Applicator for 1.00mm (.039") Pitch Wire-to-Board Crimp Terminal
PARTS LIST
FineAdjust Applicator 63901-9400
Item
Order No
Engineering No.
Description
Quantity
Perishable Tooling
63901-9470 63901-9470 Tool Kit (All “Y” Items) REF
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
63444-0705 63444-0705 Conductor Punch 1 Y
63445-0718 63445-0718 Anvil 1 Y
63454-0115 63454-0115 Insulation Punch 1 Y
63443-0003 63443-0003 Cut-Off Plunger Front 1 Y
63443-0012 63443-0012 Plunger Retainer Front 1 Y
Other Components
11-18-4083 60707-8 Feed Guide 1
11-24-1067 4996-4 Cut-off Plunger Spring 1
63443-0009 63443-0009 Scrap Chute Front 1
63443-0021 63443-0021 Lower Tooling Key 1
63443-2516 63443-2516 Anvil Mount 1
63443-2805 63443-2805 Front Plunger Striker 1
63443-2903 63443-2903 Wire Hold Down Plunger 1
63443-4029 63443-4029 Wire Stop 1
63443-6001 63443-6001 Rear Cover
63600-0021 63600-0021 Wire Hold Down Spring 1
Frame
63800-4901 63800-4901 Top 1
63801-3281 63801-3281 Base 1
63801-4650 63801-4650 Track 1
Hardware
N/A N/A M3 by 6 Long SHCS 2**
N/A N/A M4 by 6 Long SHCS 1**
N/A N/A M4 by 12 Long BHCS 2**
N/A N/A M4 by 16 Lg SHCS 1**
N/A N/A M4 by 50 Long SHCS 2**
N/A N/A 3MM by 6 Long Roll Pin 1**
N/A N/A #10-32 by 3/8” Long Flat Point SSS 1**
N/A N/A #10-32 Hex Jam Nut 1**
** Available from an industrial supply company such as MSC (1-800-645-7270).
Doc No: ATS-639019400
Revision: C
Release Date: 02-01-10
Revision Date: 03-22-11
UNCONTROLLED COPY
Page 3 of 5
